2025 Sea Ray SDX270 SURF

NEW FOR 2025!!!

CUSTOM ORDER YOUR DREAM BOAT TODAY!!!

The SDX® 270 Surf is designed to maximize every moment out on the water. The yacht-certified vessel showcases ultimate versatility with premium amenities, including powerful propulsion, an oversized bow perfect for socializing, an open cockpit with ample seating, and abundant storage areas. Plus, an intuitive surf system powered by Mercury Marine® generates rideable waves for wakesurfing and other watersports. Never compromising on comfort, the SDX 270 Surf offers everything you need for endless adventures.

STANDARD INCLUSIONS:

PROPULSION
Mercury® MerCruiser® 6.2L MPI ECT Bravo Four S® with DTS (350 hp / 261 kW)

TOPS & CANVAS
o Watersports tower, electric folding with integrated Bimini top & side-mounted surf tow points - black

WATER SYSTEM
o Ballast system, hard tank subfloor (center bow, port midship and starboard midship) - controlled by Sea Ray customized surf interface

BOW & COCKPIT
o Cup holders, stainless steel (17)
o Floor liner, fiberglass
o Lighting, LED (courtesy)
o Outlets, 12V accessory
o Outlets, USB-A & USB-C dual port (4)
o Self-bailing cockpit
o Side entry step (starboard cockpit)
o Vinyl, marine grade with mildew & UV protection

DOORS
o Bow block-off door, fiberglass
o Hatch for bilge access, gas-assisted
o Transom door, fiberglass

SEATING
o Aft L-shaped bench seating with storage below
o Bow seating, U-shaped with removable cushions & storage below
o Cockpit social area with opposing seating & storage
o Helm seat, oversized with convertible backrest & flip-up bolster
o Port companion seat with convertible backrest & flip-up bolster
o Sunpad with convertible backrest

STORAGE
o Board storage, gas-assisted with holders (under cockpit seating)
o Bow compartment, gas-assisted with concealed stainless steel four-step boarding ladder & anchor storage
o Bow storage (under seating)
o Integrated cooler or storage, fiberglass with drain (under bow seating)
o Integrated cooler or storage, fiberglass with drain (under cockpit seating)

HULL & DECK
o Cleats, stainless steel through-bolted (8´´) - 6
o Deck fill plate, stainless steel
o Drain plug
o Eyes, stainless steel (bow & stern)
o Handrails, stainless steel (bow & cockpit)
o Horn, built-in
o Light, removable (stern)
o Lights, navigation (stainless steel) - integrated into deck
o Rub rail, PVC with stainless steel insert
o Ski tow eye, stainless steel (transom)
o Stringer system, fiberglass
o Swim platform, integral with manual submersible step, concealed stainless steel four-step swim ladder & grab handle
o Thru-hull fittings, stainless steel
o Windshield, tempered tinted curved glass with walkthrough door

STORAGE
o Glove box, lockable (port dash)
o Storage, gas-assisted with drain (transom walkway floor)
o Storage (under port console)
o Storage with lockable door (under helm)
o Lighting, LED (courtesy)

ELECTRICAL
o Battery switches
o Fuse block

FUSION ® AUDIO SYSTEM
o RA210 AM/FM stereo (port dash)
o Bluetooth(TM)
o Digital Signal Processing (DSP)
o Wi-Fi audio streaming with Apple AirPlay® 2
o XS Series speakers (6.5´´) - 2 pairs

HELM
o Alarm, engine (oil & water)
o Digital Dash, dual (9´´)
o Active Trim control & monitoring
o Mercury Marine® SmartCraft® Connect
o Simrad® NSX® 9´´ touchscreen displays (2)
o Transducer with depth, water temperature & fishfinder
o Mercury Marine® SmartCraft® Digital Throttle & Shift (DTS)
o Active Trim speed-based automatic engine trim system with integrated GPS
o Engine start / stop
o Sea Ray customized surf interface powered by Mercury Marine® Smart Tow®
o Steering, power-assisted with tilt wheel
o Switch panel with illuminated weatherproof chrome switches
o Tilt & trim, power

BILGE
o Bilge lighting, 12V
o Bilge pump, 1100 GPH 12V automatic (aft)
o Blower, 12V
o Fire extinguisher discharge port
o Oil filter, remote
o Sound-insulated & gel-coated enclosure
o Vents, integral with water management system

FUEL SYSTEM
o Evaporative emissions fuel system
o Fuel lines, USCG compliant
o Fuel tank with anti-siphon valve & electric sending unit

UNDERWATER GEAR
o Propellers, stainless steel
o Surf tabs, electric


SPECIFICATIONS
LENGTH OVERALL 27´2´´ / 8.28 m without anchor 27´7´´ / 8.41 m with anchor
BEAM 8´6´´ / 2.59 m
BALLAST CAPACITY 862 kg
FUEL CAPACITY 284 L
DEADRISE 21º
DRAFT 43´´ / 109 cm (sterndrive down) 34´´ / 86 cm (sterndrive up)
CRUISING SPEED 24-28 mph / 39-45 kph
WIDE OPEN THROTTLE (WOT) 38-40 mph / 61-64 kph
DRY WEIGHT 3,164 kg
WATER READY WEIGHT 8,094 lb / 3,671 kg (fully optioned)
RANGE 154 mi / 248 km (cruising speed) 103 mi / 166 km (WOT)
WATER CAPACITY 14 gal / 53 L (requires Optional Water System Bundle)
HOLDING TANK 23 L (requires Optional Water System Bundle)
BRIDGE CLEARANCE 8´4´´ / 2.54 m (tower up) 5´8´´ / 1.73 m (tower down)

Contact us for a full list of factory options & upgrades. We can customise and order your dream boat with a 10% deposit.

*Photos may show factory options/upgrades not included in base price.
